Construction Hoist Rack and Pinion Gear Modules5 M8 Rack (Modules1~Modules10)
| Price: | US $ 12-15/Piece |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 500/Piece |
| Pay Type: | L/C,T/T,Western Union,Paypal,Money Gram |
| Prod Model: | M8 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Country Of Original: | Shanghai, China |
| Minimium Order Quantity: | First Three Orders No Limit |
| Transportation: | by Sea |
| Delivery Date: | 7 Wordking Days |
| Payment: | Tt & LC |
| Material: | Steel |
| Packing Details: | Wooden Case |
| Over Sea Sales Service: | Available |
| Steel Type: | Q235 |
| Loading Port: | Shanghai |
| Certification: | ISO9001: 2000 |
| Condition: | New |
Product Description
SHANGHAI RUIBIAO PASSENGER HOIST USE GEAR RACK
Product Description
Gear Rack For Construction Hoist, ,spur gear racks, gear rack m6, nylon gear rack, gear rack m8, precision parts, construction machinery gear racks, rack, nylon rack, metal rack, open gate racks, steel rack, guide rail are exported in big quantity to Europe and America. There is standard gear rack available and also special gear rack as per your drawing or sample
Gear rack:
1) Our gear rack is produced as per DIN standard.
2) The pressure angle: 20°/14.5°
3) Module: M0.5-M25/DP1-DP25
4) The maximum length can be 3500mm
5) The material can be Q235, C45, SS304, SS316L, aluminium, copper and so on.
6) Please feel free to let us know your detail enquiry and we will produce as per your request.
Gear Rack Standard type
Length X Width X Height (MM)
500~2000 X10X10
500~2000 X15X15
500~2000 X20X20
500~2000 X25X25
500~2000 X30X30
500~2000 X35X35
500~2000 X40X40
500~2000 X50X50
500~2000 X60X60
500~2000 X70X70
500~2000 X80X80
500~2000 X90X90
500~2000 X100X100
|
Product Description
Gear Racks:
1 produce according to drawings
2 strict quality control
3 Reasonable price and good service
Product Description
Rack including Spur Gear Rack, Helical Gear Rack, Square Gear Rack, Round Rack and Customized Special Racks. We can make the gear as your specification and drawing.
Gear Racks and Pinions for CNC Machines
We would like to produce gear racks according to your drawings and specifications.
1) Suitable for various automotive, electronic, telecommunications, mechanical products, medical devices, etc
2) Precision/tolerance:0.01mm
3)Surface processing technic : heat treatment, zinc plating,others optional can be as requirements
4)Material: iron/aluminum, copper, alloy, carbon steel, 18CrMnTi,20CrMnTi,20Cr,20CrV,1045 steel, S355J2G3, others optional
5) Products range: standard component or non-standard component. (We provide OEM service)
6)ISO9001:2008 & ISO9001:2000
Gear Rack,Gear Rack
1. construction elevator gear rack
2. We supply gear rack according to the customer's drawings or sample.
3. materail: steel C45/C60
4. It's widely used in construction elevator and other lift machine .
5. we can also provide OEM and ODM service .
We sincerely wish the cooperation with you in the relative fields!
1 produce according to drawings
2 strict quality control
3 Reasonable price and good service
M1 | 10x10x1000 10x15x1000 | M1 | 15x15x250 15x15x500 | M3 | 30x30x250 30x30x500 | M5 | 50x50x250 50x50x500 |
| M1.5 | 15x15x1000 15x20x1000 | 15x15x1000 15x15x2000 | 30x30x1000 30x30x2000 | 50x50x1000 50x50x2000 | |||
| M2 | 20x20x1000 20x25x1000 | M1.5 | 17x17x250 17x17x500 | M6 | 60x60x250 60x60x500 | ||
| M2.5 | 25x25x1000 25x30x1000 | 17x17x1000 17x17x2000 | M4 | 22x22x250 22x22x500 | 60x60x1000 60x60x2000 | ||
| M3 | 30x30x1000 30x35x1000 | M2 | 20x20x250 20x20x500 | 22x22x1000 22x22x2000 | M8 | 80x80x250 80x80x500 | |
| M4 | 40x40x1000 40x45x1000 | 20x20x1000 20x20x2000 | M4 | 30x30x250 30x30x500 | 80x80x1000 80x80x2000 | ||
| M5 | 50x50x1000 50x55x1000 | M2.5 | 25x25x250 25x25x500 | 30x30x1000 30x30x2000 | M10 | 100x100x250 100x100x500 | |
| M6 | 60x60x1000 60x65x1000 | 25x25x1000 25x25x2000 | M4 | 40x40x250 40x40x500 | 100x100x1000 100x100x2000 | ||
| M8 | 80x80x1000 | M8 | 40*60*1508 | 40x40x1000 40x40x2000 | M5 | 40*60*1508 |
Product Description
Rack including Spur Gear Rack, Helical Gear Rack, Square Gear Rack, Round Rack and Customized Special Racks. We can make the gear as your specification and drawing.
Gear Racks and Pinions for CNC Machines
We would like to produce gear racks according to your drawings and specifications.
1) Suitable for various automotive, electronic, telecommunications, mechanical products, medical devices, etc
2) Precision/tolerance:0.01mm
3)Surface processing technic : heat treatment, zinc plating,others optional can be as requirements
4)Material: iron/aluminum, copper, alloy, carbon steel, 18CrMnTi,20CrMnTi,20Cr,20CrV,1045 steel, S355J2G3, others optional
5) Products range: standard component or non-standard component. (We provide OEM service)
6)ISO9001:2008 & ISO9001:2000
Gear Rack,Gear Rack
1. construction elevator gear rack
2. We supply gear rack according to the customer's drawings or sample.
3. materail: steel C45/C60
4. It's widely used in construction elevator and other lift machine .
5. we can also provide OEM and ODM service .
We sincerely wish the cooperation with you in the relative fields!
material | steel C45/C60 |
| size | 40×60×1508mm , M8 |
usage | construction elevator |
Shanghai RuiBiao Construction Machinery Co., Ltd is the special maker of power precision transmission products of gear racks, slewing ring bearings, safety devices and gearboxes, Anemometer Wind Speed Meter, Overload Indicator and Sensor, Worm and Worm Wheel, Hoist Spare Parts for construction, engineering, lifters, lifting elevators, hoists, and machinery transmission. Our products are mainly exported to Malaysia, Italy, the USA, Spain, Greece, Turkey and Russia. We can satisfy our customers' needs well. We can produce products according to customers' special requirements.
We are making precision casting parts according to customer's technical requirements
We sincerely hope to cooperate with friends in the fields!
